Backup Immich to GCS

Prerequisites

Google Cloud CLI Setup

1. Install Google Cloud CLI (gcloud) if not already installed:

Copy Allsudo apt update
sudo apt install apt-transport-https ca-certificates gnupg curl
echo "deb [signed-by=/usr/share/keyrings/cloud.google.gpg] https://packages.cloud.google.com/apt cloud-sdk main" | sudo tee -a /etc/apt/sources.list.d/google-cloud-sdk.list
curl https://packages.cloud.google.com/apt/doc/apt-key.gpg | sudo apt-key --keyring /usr/share/keyrings/cloud.google.gpg add -
sudo apt update && sudo apt install google-cloud-sdk

2. Configure Google Cloud CLI with your credentials:

gcloud initCopy

Follow the prompts to log in to your Google account, select your GCP project, and set the default region (e.g., asia-south1 for Mumbai).

3. Authenticate with a Service Account (recommended for automation):

• Create a service account in the GCP Console under IAM & Admin > Service Accounts.

• Assign the role Storage Admin (roles/storage.admin) to the service account.

• Generate and download a JSON key file for the service account.

• Set the key file for authentication:

gcloud auth activate-service-account --key-file=/path/to/service-account-key.jsonCopy

GCS Bucket Setup

1. Create a GCS Bucket via the Google Cloud Console or CLI:

gsutil mb -l asia-south1 gs://immich-backups-adityaCopy

Replace immich-backups-aditya with a globally unique bucket name and asia-south1 with your preferred region.

2. Enable Versioning to protect against accidental overwrites:

gsutil versioning set on gs://immich-backups-adityaCopy

Automate Backups with a Cron Job

1. Create a Backup Script

Create a script to handle the backup process:

nano /home/ubuntu/immich-app/backup_to_gcs.shCopy

Add the following content:

Copy All#!/bin/bash
# Configuration
GCS_BUCKET="gs://immich-backups-aditya"
DB_BACKUP_DIR="Daily_Database_Backup"
DATA_DIR="/mnt/immich_data/upload"  # Adjust if your data is elsewhere
BACKUP_DATE=$(date +%Y%m%d)
LOG_FILE="/var/log/immich_backup.log"
DIRECTORIES=("backups" "library" "encoded-video" "thumbs" "upload" "profile")

# Function to log messages
log() {
  echo "[$(date '+%Y-%m-%d %H:%M:%S')] $1" | tee -a "$LOG_FILE"
}

# Ensure log file exists and is writable
sudo touch "$LOG_FILE"
sudo chown $(whoami):$(whoami) "$LOG_FILE"
sudo chmod 644 "$LOG_FILE"

# Verify gsutil authentication
if ! gsutil ls "$GCS_BUCKET" >/dev/null 2>&1; then
  log "ERROR: Cannot access GCS bucket $GCS_BUCKET. Check authentication."
  exit 1
fi
log "GCS bucket $GCS_BUCKET is accessible"

# Stream database backup directly to GCS
log "Starting database backup"
if ! docker exec -t immich_postgres pg_dumpall --clean --if-exists --username=postgres | gzip | gsutil -h "x-goog-storage-class:COLDLINE" cp - "$GCS_BUCKET/$DB_BACKUP_DIR/immich_db_$BACKUP_DATE.sql.gz"; then
  log "ERROR: Database backup failed"
  exit 1
fi
log "Database backup completed: immich_db_$BACKUP_DATE.sql.gz"

# Sync application data directories directly to GCS
for dir in "${DIRECTORIES[@]}"; do
  log "Checking directory: $DATA_DIR/$dir"
  if [ ! -d "$DATA_DIR/$dir" ]; then
    log "WARNING: Directory $DATA_DIR/$dir does not exist or is not accessible, skipping"
    continue
  fi

  # Check if directory has files (better method that handles hidden files)
  if [ -z "$(find "$DATA_DIR/$dir" -maxdepth 1 -type f -print -quit)" ]; then
    log "WARNING: Directory $DATA_DIR/$dir appears to be empty, skipping"
    continue
  fi

  log "Syncing directory: $dir"
  # Fixed rsync command with proper options and error handling
  if ! gsutil -m -h "x-goog-storage-class:COLDLINE" rsync -r -d "$DATA_DIR/$dir/" "$GCS_BUCKET/$dir/" 2>&1 | tee -a "$LOG_FILE"; then
    log "ERROR: Sync of $dir failed"
    exit 1
  fi
  log "Sync of $dir completed"
done

# Keep only the latest 20 database backups
log "Checking for old database backups to delete"

# List files, filter for immich_db_*.sql.gz, sort newest first, skip latest 20, delete the rest
backup_files=$(gsutil ls "$GCS_BUCKET/$DB_BACKUP_DIR/immich_db_*.sql.gz" 2>/dev/null | sort -r)
if [ -n "$backup_files" ]; then
  echo "$backup_files" | tail -n +21 | while read -r file; do
    if [ -n "$file" ]; then
      if gsutil rm "$file" 2>&1 | tee -a "$LOG_FILE"; then
        log "Deleted old backup: $file"
      else
        log "ERROR: Failed to delete: $file"
      fi
    fi
  done
else
  log "No database backups found for cleanup"
fi

log "Cleanup of old backups completed"
log "Backup process finished successfully"

2. Run the Script to Test

bash /home/ubuntu/immich-app/backup_to_gcs.shCopy

3. Make the Script Executable

chmod +x /home/ubuntu/immich-app/backup_to_gcs.shCopy

3. Schedule Daily Backup

Schedule the script to run daily at 3 AM:

crontab -eCopy

Add the following line:

0 3 * * * /home/ubuntu/immich-app/backup_to_gcs.shCopy

Notes

• Storage Class: The script uses the coldline storage class for cost efficiency, suitable for infrequent access. You can change it to standard or nearline based on your needs.

• Permissions: Ensure the service account has the necessary permissions (storage.objects.create, storage.objects.delete, storage.objects.list) to manage objects in the bucket.

Logging: The script logs operations to /var/log/immich_backup.log. Ensure the directory exists and is writable:

sudo mkdir -p /var/logCopy
sudo touch /var/log/immich_backup.logCopy
sudo chown ubuntu:ubuntu /var/log/immich_backup.logCopy

• Versioning: Enabling versioning ensures you can recover from accidental deletions or overwrites. Use gsutil ls -a to view object versions if needed.

Testing: Test the script manually first (bash /home/ubuntu/immich-app/backup_to_gcs.sh) to ensure it works as expected.

For more details on Google Cloud Storage, refer to
