Immich Nginx SSL Setup

Prerequisites

• Immich Server: Ensure your Immich server is running and accessible locally (e.g., at http://localhost:2283 or the internal IP of your server)

• Domain: You own the domain example.your-domain-name.com and have access to its DNS settings

• Server: You have a server with Nginx installed and root or sudo access

• DNS Setup: Point your domain example.your-domain-name.com to your server's public IP address by creating an A record in your DNS provider's control panel

Step 1: Configure Nginx for Your Custom Domain

We'll create an Nginx configuration to proxy requests from example.your-domain-name.com to your Immich server.

1. Create an Nginx Configuration File:

Open a terminal on your server and create a new Nginx configuration file:

sudo apt install nginxCopy
sudo nano /etc/nginx/sites-available/immichCopy

2. Add the Nginx Configuration:

Based on the Immich documentation, use the following configuration. Replace <backend_url> with the internal address of your Immich server (e.g., localhost or your server's internal IP):

Copy Allserver {
    server_name example.your-domain-name.com;

    # Allow large file uploads
    client_max_body_size 50000M;

    # Set headers
    proxy_set_header Host              $host;
    proxy_set_header X-Real-IP         $remote_addr;
    proxy_set_header X-Forwarded-For   $proxy_add_x_forwarded_for;
    proxy_set_header X-Forwarded-Proto $scheme;

    # Enable WebSockets
    proxy_http_version 1.1;
    proxy_set_header   Upgrade    $http_upgrade;
    proxy_set_header   Connection "upgrade";
    proxy_redirect     off;

    # Set timeout for long-running processes (e.g., Repair page)
    proxy_read_timeout 600s;
    proxy_send_timeout 600s;
    send_timeout       600s;

    # Proxy all requests to Immich
    location / {
        proxy_pass http://localhost:2283;
    }

    # Ensure Let's Encrypt compatibility for /.well-known/immich
    location = /.well-known/immich {
        proxy_pass http://localhost:2283;
    }
}

Notes: Replace http://localhost:2283 with the actual address of your Immich server if it's running on a different host or port. The location = /.well-known/immich block ensures compatibility with Immich's mobile clients.

3. Enable the Configuration:

Create a symbolic link to enable the site:

sudo ln -s /etc/nginx/sites-available/immich /etc/nginx/sites-enabled/Copy

4. Test the Nginx Configuration:

Verify the configuration for syntax errors:

sudo nginx -tCopy

5. Reload Nginx:

Apply the changes by reloading Nginx:

sudo systemctl reload nginxCopy

6. Test Access:

Open a browser and navigate to http://example.your-domain-name.com. If your DNS is correctly set up and Immich is running, you should see the Immich web interface.

Step 2: Add SSL Certificate with Let's Encrypt

To secure your domain with HTTPS, we'll use Let's Encrypt with Certbot to obtain and install an SSL certificate.

1. Install Certbot:

On Ubuntu/Debian, install Certbot and the Nginx plugin:

sudo apt updateCopy
sudo apt install certbot python3-certbot-nginxCopy

2. Obtain an SSL Certificate:

Run Certbot to automatically obtain and configure the SSL certificate for your domain:

sudo certbot --nginx -d example.your-domain-name.comCopy

Follow the prompts: Provide an email address for renewal notifications, agree to the terms of service, and choose whether to redirect HTTP traffic to HTTPS (recommended: select the redirect option).

3. Automatic Nginx Configuration:

Certbot will modify your Nginx configuration to include SSL settings. Your updated Nginx configuration will look like this:

Copy Allserver {
    server_name example.your-domain-name.com;

    # Allow large file uploads
    client_max_body_size 50000M;

    # Set headers
    proxy_set_header Host              $host;
    proxy_set_header X-Real-IP         $remote_addr;
    proxy_set_header X-Forwarded-For   $proxy_add_x_forwarded_for;
    proxy_set_header X-Forwarded-Proto $scheme;

    # Enable WebSockets
    proxy_http_version 1.1;
    proxy_set_header   Upgrade    $http_upgrade;
    proxy_set_header   Connection "upgrade";
    proxy_redirect     off;

    # Set timeout for long-running processes
    proxy_read_timeout 600s;
    proxy_send_timeout 600s;
    send_timeout       600s;

    # Proxy all requests to Immich
    location / {
        proxy_pass http://localhost:2283;
    }

    # Ensure Let's Encrypt compatibility for /.well-known/immich
    location = /.well-known/immich {
        proxy_pass http://localhost:2283;
    }

    listen 443 ssl; # managed by Certbot
    ssl_certificate /etc/letsencrypt/live/example.your-domain-name.com/fullchain.pem; # managed by Certbot
    ssl_certificate_key /etc/letsencrypt/live/example.your-domain-name.com/privkey.pem; # managed by Certbot
    include /etc/letsencrypt/options-ssl-nginx.conf; # managed by Certbot
    ssl_dhparam /etc/letsencrypt/ssl-dhparams.pem; # managed by Certbot
}

server {
    if ($host = example.your-domain-name.com) {
        return 301 https://$host$request_uri;
    } # managed by Certbot

    listen 80;
    server_name example.your-domain-name.com;
    return 404; # managed by Certbot
}

4. Test the Nginx Configuration:

Verify the updated configuration:

sudo nginx -tCopy

5. Reload Nginx:

Apply the changes:

sudo systemctl reload nginxCopy

6. Test HTTPS Access:

Visit https://example.your-domain-name.com in your browser. You should see the Immich web interface over a secure connection.

Troubleshooting

DNS Issues: Ensure example.your-domain-name.com resolves to your server's IP using dig example.your-domain-name.com or ping example.your-domain-name.com

Firewall: Allow ports 80 and 443:

sudo iptables -I INPUT -p tcp --dport 80 -m state --state NEW -j ACCEPTCopy
sudo iptables -I INPUT -p tcp --dport 443 -m state --state NEW -j ACCEPTCopy
sudo apt-get updateCopy
sudo apt-get install iptables-persistent -yCopy
sudo netfilter-persistent saveCopy
sudo netfilter-persistent reloadCopy
sudo ufw allow 80Copy
sudo ufw allow 443Copy

Step 3: Verify Immich Compatibility

• Mobile Client Access: Ensure the /.well-known/immich path is correctly proxied. Test by accessing Immich from a mobile client to confirm you don't get the 'Your app major version is not compatible with the server' error

• Large File Uploads: The client_max_body_size 50000M setting allows uploads up to 50GB. Adjust if needed for your use case

• Timeouts: The 600-second timeouts should prevent issues with the Repair page or large uploads

Step 4: Automate Certificate Renewal

Let's Encrypt certificates expire every 90 days, but Certbot sets up automatic renewal.

1. Test Renewal:

Simulate a certificate renewal:

sudo certbot renew --dry-runCopy

2. Verify Cron Job:

Certbot typically adds a cron job or systemd timer to renew certificates automatically. Check with:

sudo systemctl status certbot.timerCopy

If not enabled, enable it:

sudo systemctl enable certbot.timerCopy
sudo systemctl start certbot.timerCopy

Troubleshooting

DNS Issues: Ensure example.your-domain-name.com resolves to your server's IP using dig example.your-domain-name.com or ping example.your-domain-name.com

Firewall: Allow ports 80 and 443:

sudo iptables -I INPUT -p tcp --dport 80 -m state --state NEW -j ACCEPTCopy
sudo iptables -I INPUT -p tcp --dport 443 -m state --state NEW -j ACCEPTCopy
sudo apt-get updateCopy
sudo apt-get install iptables-persistent -yCopy
sudo netfilter-persistent saveCopy
sudo netfilter-persistent reloadCopy
sudo ufw allow 80Copy
sudo ufw allow 443Copy

Immich Not Loading: Verify the Immich server is running (curl http://localhost:2283) and check Nginx access logs (/var/log/nginx/access.log)

SSL Errors: Ensure Certbot installed correctly and the certificate paths in the Nginx config are valid

Final Notes

• Your Immich instance is now accessible at https://example.your-domain-name.com with proper SSL termination

• The configuration adheres to Immich's requirements (root path, headers, timeouts, and /.well-known/immich compatibility)

• Regularly monitor your server and certificate status to ensure uninterrupted service

This setup ensures your Immich server is accessible via a custom domain with proper SSL security and mobile client compatibility.
